FHW Fan Section Data

　

Model

Air Flow M3/h

Unit Size (mm)

Blower

External SP (Pa)

RPM

Motor (KW)

380 / 3 / 50

H

W

D
310 31000 2100 2200 1900 FDA/710/C 400 443 7.5
700 613 15
360 36000 2100 2440 1900 FDA/710/C 400 443 11
700 604 15
410 41000 2100 2750 1500 FDA/560/T2 400 558 11
700 791 18.5
530 53000 2400 3050 1500 FDA/560/T2 400 558 15
700 725 22
600 60000 2400 3350 1700 FDA/630/T2 400 498 18.5
700 669 30
650 65000 2400 3650 1900 FDA/710/C/2 400 443 7.5 x 2
700 621 15 x 2
720 72000 2400 3950 1900 FDA/710/C/2 400 443 11 x 2
700 613 15 x 2
850 85000 2800 3950 2100 FDA/800/C/2 400 378 11 x 2
700 524 8.5 x 2

　
