FCW Fan Section Data

　

Model

Air Flow M3/h

 Unit Size (mm) Blower External SP (Pa) RPM Motor (KW)
H W D
030 3000 850 900 800 KAT/10/C 400 1160 0.75
700 1595 1.5
040 4000 850 950 800 KAT/10/C 400 1088 1.1
700 1611 2.2
050 5000 850 1200 850 KAT/12/C 400 1004 1.5
700 1450 3
070 7000 850 1550 1100 KAT/15/11/C 400 768 2.2
700 1186 3
085 8500 950 1850 1100 KAT/18/13/C 400 653 2.2
700 967 4
100 10000 950 2150 1100 KAT/18/13/C 400 687 3
700 932 4
125 12500 1000 2150 1100 KAT/18/C 400 682 3
700 967 5.5
150 15000 1150 2150 1200 KAT/15/11/C2 400 806 4
700 906 7.5
175 17500 1300 2150 1400 KAT/18/13/C2 400 725 5.5
700 938 7.5
200 20000 1500 2150 1500 KAT/18/13/C2 400 725 5.5
700 938 11
230 23000 1650 2150 1500 KAT/18/13/C2 400 725 7.5
700 906 11
260 26000 1800 2200 1700 KAT/18/18/C2 400 725 7.5
700 997 11

　
