AHU Coil Section Data

In Temperature

DB 27c / WB 19.50c

Water In 7c/ Water Out 12c

　

Model

Air Flow M3/h

Face Velocity

M/s

4 row 12 fin / inch

6 row 10 fin / inch

Total Heat

kW

Sensible Heat

kW

Water Flow

L/s

WPD

KPa

APD (wc)

Pa

Total Heat

kW

Sensible Heat

kW

Water Flow

L/s

WPD

KPa

APD (wc)

Pa
030 3000 2.5 14.13 12.41 0.68 10.23 98 17.66 13.91 0.84 8.37 125
040 4000 2.5 16.96 14.45 0.81 8.44 98 22.25 16.70 1.06 15.70 125
050 5000 2.5 22.96 20.65 1.10 14.78 98 28.26 22.25 1.35 9.56 125
060 6000 2.5 28.97 25.81 1.38 22.90 98 37.09 28.81 1.77 16.22 125
070 7000 2.5 35.32 30.15 1.69 32.23 98 44.15 33.53 2.11 24.17 125
085 8500 2.5 45.92 37.72 2.19 27.52 98 56.52 41.94 2.70 41.70 125
100 10000 2.5 60.05 46.95 2.87 49.38 98 74.18 53.70 3.54 35.14 125
125 12500 2.5 70.65 56.53 3.38 43.46 98 88.31 64.97 4.22 30.38 125
150 15000 2.5 91.84 70.34 4.39 15.65 98 105.97 77.93 5.06 30.37 125
175 17500 2.5 109.50 85.07 5.23 18.27 98 123.63 90.98 5.91 30.38 125
200 20000 2.5 127.16 97.27 6.08 18.28 98 144.83 104.03 6.92 30.39 125
230 23000 2.5 144.83 109.3 6.92 18.26 98 162.49 116.89 7.76 30.37 125
260 26000 2.5 164.25 124.82 7.85 18.54 98 183.68 133.49 8.78 35.66 125
310 31000 2.5 197.81 149.92 9.45 18.55 98 219.01 160.33 10.46 35.68 125
360 36000 2.5 227.84 170.14 10.89 26.35 98 250.8 181.96 11.98 43.64 125
410 41000 2.5 254.33 194.37 12.15 35.50 98 286.12 207.87 13.67 21.61 125
530

53000

2.5

335.57

255.21

16.03

48.24

98

388.56

281.80

18.56

30.78

125
600

60000

2.5

363.83

283.46

17.38

57.04

98

441.54

312.98

21.10

41.00

125
650

65000

2.5

395.62

311.87

18.90

12.12

98

487.46

344.36

23.29

49.46

125
720

72000

2.5

452.14

340.29

21.60

14.98

98

529.85

375.73

25.32

64.70

125
850

85000

2.5

540.45

405.14

25.82

14.98

98

628.76

447.34

30.04

64.71

125



back



PAU Coil Section Data

In Temperature

 DB 34c / WB 28c

 Water In 7c/ Water Out 12c



Model

Air Flow M3/h

Face Velocity

M/s

Unit Size

4 row 12 fin / inch

6 row 10 fin / inch

Cooling Capacity

kW

Sensible Heat

kW

Water Flow

L/s

WPD

KPa

APD (wc)

Pa

H

W

D
030 3000 2.5 1350 900 　600 35.32 15.41 1.69 27.97 98
45.92 19.41 2.19 39.06 125
040 4000 2.5 1400 950 　600 42.39 18.64 2.03 36.17 98
52.99 22.28 2.53 25.16 125
050 5000 2.5 1500 1200 　600 63.58 27.70 3.04 39.30 98
77.71 32.76 3.71 25.18 125
070 7000 2.5 1500 1550 　600 77.71 34.68 3.71 19.73 98
102.44 42.56 4.89 49.30 125
085 8500 2.5 1650 1850 　600 109.50 47.57 5.23 42.69 98
123.63 51.79 5.91 24.90 125
100 10000 2.5 1650 2150 　600 123.63 53.70 5.91 9.96 98
155.42 65.53 7.43 41.77 125
125 12500 2.5 1800 2150 　600 144.83 64.97 6.92 8.53 98
194.28 81.85 9.28 41.76 125
150 15000 2.5 1950 2150 600　 190.75 82.99 9.11 9.95 98
226.07 95.64 10.80 41.74 125
175 17500 2.5 2200 2150 600　 226.07 96.89 10.80 9.96 98
261.39 108.70 12.49 37.85 125
200 20000 2.5 2450 2150 　800 257.86 110.78 12.32 9.96 98
300.25 127.67 14.35 37.86 125
230 23000 2.5 2850 2150 　800 289.65 124.48 13.84 9.95 98
339.11 143.46 16.20 41.74 125
260 26000 2.5 1800 2200 　800 324.98 142.15 15.53 10.09 98
399.16 168.16 19.07 47.68 125
310 31000 2.5 2100 2200 　800 388.56 170.74 18.56 10.10 98
476.87 201.98 22.78 42.40 125
360 36000 2.5 2100 2440 　800 455.67 193.77 21.77 14.26 98
529385 223.31 25.32 9.25 125
410 41000 2.5 2100 2750 　800 522.79 221.37 24.98 19.10 98
614.63 255.12 29.37 13.29 125
530 53000 2.5 2400 3050 　800 628.76 272.94 30.04 23.15 98
812.44 343.83 38.82 16.48 125
